Welcome to our site, with introduction of chain link fence and other wire mesh fences from China. Covering specific sizes, materials, fence structures, edge treatment, fittings, packing, installation of fence fabrics and chain link gates, together with photo illustrations.

1" & 2” Mesh Chain Link Fence

1 inch and 2 inch are the common sizes of mesh opening for chain link wire fabric. Wire gauges applied for making one inch mesh opening chain link fence are BWG12, 14 and 16. Wire gauges applied for making 2” chain link fence are BWG8, 10 and 11.

Materials applied: Galvanized steel, stainless steel, aluminum and plastic coated steel. Galvanized chain link fence is the most popular and economic material compared with chain link fences made of stainless steel, aluminum and plastic coated.

Coating colors options: Green, yellow, white, black, other colors also available.


Edge Types: Wire Wrapped and Twisted, Illustration Photo as Below:

Wrapped Wire Edge Treatment for Chain Link Fence



Twisted Wire Edge

Specification with Mesh, Wire Gauge, Unit Weight

Mesh Opening of Chain Link Fabric Wire Gauge (BWG) Fence Weight
(kg/m2)
1" 12 4.0
1" 14 2.4
1" 16 1.4
2" 8 4.16
2" 10 3.0
2" 11 2.5
2" 12 2.0

Uses: Chain link fences with 1” & 2” opening are mainly used as fences for mine exploitation perimeter, pet fence, playground and gardens, super highway, railway, airports, etc.

3/4" & 3/2" Mesh Chain Link Fence
3/4" & 3/2" are small sizes of mesh opening for chain link wire fabric. Wire gauges applied for making 3/4" mesh opening chain link fence are BWG12, 14 and 16 while wire gauges for making 3/2" chain link fence are BWG10, 12 and 14.


Specification with Mesh, Wire Gauge, Unit Weight

Mesh Opening of Chain Link Fabric Wire Gauge (BWG) Fence Weight
(kg/m2)
3/4" 12 6.0
3/4" 14 3.3
3/4" 16 1.9
3/2" 10 4.0
3/2" 12 2.7
3/2" 14 1.6



General Introduction to Chain Link Fences:
Materials
Fence Fabric Structure
Fittings for Chain Link Fences
Packing
Installation Tools
Installation of Chain Link Fence and Chain Link Gates

+++++++++++++++++++++++++++++++++++++++
Packing

Chain Link Fence can be delivered in rolls or panels.
Common packing process is to pack the two sides of the fence fabrics by paper wrapping, then pack the whole rolls with plastic bags.
Then put into wooden cases or pallets for shipment.



++++++++++++++++++++++++++++++++++
Sports Fence

Sports fencing has a high panel size with excellent anti-climbing property. Sports fencing is a kind of perimeter fence that can be installed on site.

The feature of sports fencing is its flexible panel structure, style and sizes.

Materials: High quality low carbon steel wire
Structure: Welded fence fabrics
Surface treatment: Electro galvanized, hot dipped zinc plating, usually plastic coated
Common sizes: Wire diameter: 3.8mm; opening 50mmx50mm; panel sizes: 3mx4m;fence post: 60/2.5mm; vertical post: 48/2mm
Colors: White, green, blue
Features: Corrosion resistant, aging resistant, sunshine resistant. Sports fence has flat surface, good tension of panels, keeping shapes, easy installation and adjustment.

++++++++++++++++++++++++++++++++++++
Temporary Fence

Temporary fence is also known as mobile fence, is ideal for any project, including commercial and domestic sites or special events. Temporary fence has versatile application and cover a broad range of uses including construction sites, housing construction, special events, protection and crowd control.

Fence panel materials applied for temporary fencing include:
Chain link fence;
Plastic netting fence;
Welded wire panels.

++++++++++++++++++++++++++++++++++++++++
We also supply garden fence, welded mesh fence, barbed wire and other wire products for export.
